Оригинальный
номер |
Название |
Заказ |
| (20A) |
191971926B |
grommet 33,5 |
|
| (23) |
191813327 |
mounting for tail light left |
|
| (24) |
191813335A |
reinforcement for water drain channel left lower |
|
| (25) |
191813341 |
reinforcement for water drain channel left upper |
|
| (26) |
411803595 |
cover 136MM |
|
| (32) |
N 90231601 |
weld pin order unit 100 FD-5X25 |
|
| (6) |
191803504A |
longitudinal member right rear |
|
| (6A) |
191803513C |
mounting for rear axle beam also use: left N 100 704 03 |
|
| (6A) |
191803514C |
mounting for rear axle beam also use: right N 100 704 03 |
|
| - |
161253311 |
bracket for exhaust pipe |
|
| - |
N 90243001 |
seal 18X40 |
|
| - |
N 10070403 |
hexagon head bolt c/w shoulder M10X30 |
|
| - |
N 0116552 |
washer 11,5X21X1,8 |
|
| 1 |
191813115 |
boot floor plate use if required: 357 803 272 1H0 803 745 191 803 746 |
|
| 10 |
191813120C |
carrier panel right lower |
|
| 11 |
191803477 |
reinforcement for jack socket |
|
| 12 |
191809073 |
carrier panel left 2 doors |
|
| 13 |
191809074 |
carrier panel right 2 doors |
|
| 14 |
191803611 |
bracket for tow rope rear |
|
| 15 |
191803545 |
bracket for exhaust silencer |
|
| 16 |
191803531A |
cross member |
|
| 17 |
1H6813227 |
connecting plate for longitudinal member left |
|
| 18 |
1H6813228 |
connecting plate for longitudinal member right |
|
| 19 |
191813301H |
rear apron adapt with workshop equipment |
|
| 1A |
1H0813141D |
seat support |
|
| 2 |
1H0803745 |
bracket for strap left rear |
|
| 20 |
191813305G |
rear apron adapt with workshop equipment |
|
| 22 |
191813315 |
lock carrier |
|
| 23 |
191813328 |
mounting for tail light right |
|
| 24 |
191813332 |
reinforcement for water drain channel right lower |
|
| 25 |
191813342 |
reinforcement for water drain channel right upper |
|
| 26 |
191813589 |
locking cover 130 |
|
| 27 |
N 90146604 |
cover plate 40 grey |
|
| 28 |
6X0803959 |
cover for sender unit |
|
| 29 |
321803963 |
seal |
|
| 2A |
191803746 |
bracket for strap right rear |
|
| 3 |
357803272 |
bracket for spare wheel |
|
| 30 |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| 31 |
N 10034401 |
plug C30 |
|
| 32 |
N 90175701 |
weld pin order unit 100 5X12 |
|
| 4 |
861803899B |
nut for spare wheel mounting |
|
| 5 |
191803503A |
longitudinal member left rear |
|
| 7 |
1H6813125A |
reinforcement for bumper attachment left |
|
| 8 |
1H6813126A |
reinforcement for bumper attachment right |
|
| 9 |
191813119C |
carrier panel left lower |
|
