Оригинальный номер |
Название |
Заказ |
(1) |
6Q0819480 |
gasket heat exchanger |
|
(11) |
6Q2815135A |
bracket for fan rhd |
|
(11) |
6Q1815135A |
bracket for fan lhd |
|
(12) |
6Q2819351A |
air distribution housing rhd |
|
(13) |
6Q2819303A |
intake shaft rhd |
|
(22) |
6Q2819007 |
housing rhd |
|
(25) |
6Q0819653 |
filter element with odor and harmful substances filltration |
|
(28) |
6Q0819647 |
frame |
|
(31) |
6Q2819453 |
positioning motor for recirculated air operation F >> 9N-4-210 000* rhd |
|
(31) |
6Q2819453B |
positioning motor for recirculated air operation F 9N-4-210 001>>* rhd |
|
(31) |
6Q1819453C |
positioning motor for recirculated air operation F 9N-4-210 001>>* lhd |
|
(38) |
8Z2819133 |
operating mechanism LUFTVERTEILUNG rhd |
|
(7) |
6Q0819875C |
air distribution housing for models with supplementary heater lower |
|
(7) |
6Q0819875B |
air distribution housing for models without auxiliary heater lower |
|
(9) |
6Q2819015C |
blower rhd |
|
(9) |
6Q1819015E |
blower lhd |
|
10 |
6Q0819750 |
retainer |
|
12 |
6Q1819351A |
air distribution housing lhd |
|
13 |
6Q1819303A |
intake shaft lhd |
|
14 |
6Q0819165 |
gasket |
|
17 |
6Q0819549 |
retaining bracket |
|
18 |
N 90732101 |
torx socket head panel screw 4X16-Q |
|
19 |
8D1820245 |
clips lhd |
|
2 |
6Q0819031 |
heat exchanger |
|
22 |
6Q1819007 |
housing lhd |
|
25 |
6Q0820367 |
dust and pollen filterelement |
|
27 |
6Q0819422A |
covering dust and pollen filter |
|
3 |
6Q0963235 |
additional heater PTC |
|
30 |
N 90729002 |
fillister head bolt (combi.) EM5X16-Z2 |
|
31 |
6Q1819453 |
positioning motor for recirculated air operation F >> 9N-4-210 000* lhd |
|
38 |
8Z1819133 |
operating mechanism LUFTVERTEILUNG lhd |
|
4 |
6Q0819345A |
grommet |
|
5 |
6Q0819134 |
throttle control element |
|
6 |
6Q0819133 |
operating mechanism fresh air flap |
|
8 |
6Q0959263 |
series resistor |
|
