Оригинальный
номер |
Название |
Заказ |
| (1) |
036129711CC |
intake connection F >> 9N-2D035 000* F >> 9N-2Y040 000* |
|
| (1) |
036129711DP |
suction pipe F 9N-2D035 001>>* F 9N-2Y040 001>>* F >> 9N-3-300 000 |
|
| (1) |
036129711FM |
intake connection F 9N-4-000 001>>* |
|
| (14) |
6Q0133352K |
connecting hose |
|
| (14) |
6Q0133352P |
connecting hose F 9N-4-000 001>> |
|
| (20) |
036131521AD |
connecting pipe |
|
| (20) |
036131521BF |
connecting pipe F 9N-4-000 001>> |
|
| (21) |
036131550J |
gasket F 9N-4-000 001>> |
|
| (22) |
N 10419701 |
oval head panel screw F 9N-4-000 001>> 6X22 |
|
| (30) |
036131547F |
gasket |
|
| (31) |
036131547F |
gasket |
|
| (9) |
03C906051 |
thrust sensor F 9N-4-000 001>> |
|
| 10 |
N 10404501 |
allen key head bolt F 9N-2-000 001>> F >> 9N-3-300 000 M4X16 |
|
| 10 |
N 10442001 |
torx socket head panel screw F 9N-4-000 001>> 5X16-Q |
|
| 11 |
N 10022602 |
allen key head bolt M8X38 |
|
| 12 |
036133062L |
throttle valve control unit also use: 035 133 335 N 100 834 01 |
|
| 13 |
N 10099301 |
allen key head bolt (combi) M6X65 |
|
| 14 |
6Q0133352L |
connecting hose F 9N-2-000 001>> F >> 9N-3-300 000 M4X16 |
|
| 15 |
N 10292201 |
spring-type clip A14X12 |
|
| 16 |
6Q0906517 |
valve |
|
| 17 |
6Q0133459A |
support ring |
|
| 18 |
6Q0133519A |
bracket for valve |
|
| 19 |
036131503R |
exhaust recirculation valve |
|
| 2 |
036133255E |
intermediate flange F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 20 |
036131521AC |
connecting pipe F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 21 |
036131550A |
gasket F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 22 |
N 0147452 |
allen key head bolt F 9N-2-000 001>> F >> 9N-3-300 000 M6X14 |
|
| 23 |
N 90413004 |
hexagonal head bolt 6X19 |
|
| 24 |
036133773D |
connecting hose |
|
| 25 |
037133843A |
filter |
|
| 26 |
N 0147263 |
allen key head bolt M8X30 |
|
| 27 |
036131550H |
gasket |
|
| 29 |
036131818A |
adapter |
|
| 3 |
036133073 |
gasket 64X2,3X5,6 |
|
| 32 |
N 0230038 |
shouldered hex. nut, self-locking AM8 |
|
| 33 |
N 10083401 |
clamp 14,8X6X1 |
|
| 34 |
035133335 |
cap 8 |
|
| 4 |
036129717E |
gasket 45X2,3X4,9 |
|
| 5 |
036133161C |
gasket F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 6 |
N 90434702 |
oval head panel screw F 9N-2-000 001>> F >> 9N-3-300 000 E4,8X16 |
|
| 7 |
036129720 |
locking cover F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 8 |
036129530 |
non-return valve F 9N-2-000 001>> F >> 9N-3-300 000 |
|
| 9 |
036906051 |
thrust sensor F 9N-2-000 001>> F >> 9N-3-300 000 |
|
