Оригинальный
номер |
Название |
Заказ |
| (13) |
1J0937724 |
flat contact housing with helper contact catch 3 pin black |
|
| (13) |
1J0937723 |
flat contact housing with helper contact catch 3 pin black |
|
| (18) |
4B0937545C |
bracket for connector housing left |
|
| (5) |
6Q0963556A |
heater element-seat F 9N-3D033 760>>*9N-4-270 000* F 9N-3Y046 340>> 9N-4-270 000* side |
|
| (5) |
6Q0963556A |
heater element-seat F 9N-4-270 001>>* side |
|
| 1 |
6Q0963555B |
heater element-seat F >> 9N-3D033 759* F >> 9N-3Y046 339 |
|
| 10 |
1J0972702 |
flat contact housing connecting part backrest 2 pin |
|
| 11 |
1J0972712 |
flat connector housing with additional contact catch 2 pin black |
|
| 12 |
1J0972722 |
flat terminal pin housing 4 pin |
|
| 14 |
1J0972732 |
flat terminal pin housing 4 pin |
|
| 16 |
7L0972623A |
rd. connector sleeve housing 8 pin |
|
| 18 |
4B0937545B |
bracket for connector housing right |
|
| 20 |
N 0139705 |
oval head panel screw B4,8X9,5 |
|
| 3 |
6Q0963557 |
backrest heater element F >> 9N-3D033 759* F >> 9N-3Y046 339 |
|
| 5 |
6Q0963556A |
heater element-seat F >> 9N-3D033 759* F >> 9N-3Y046 339 side |
|
| 8 |
6Q0959772 |
control unit for heated seat |
|
