Оригинальный
номер |
Название |
Заказ |
| (1) |
3B0809204C |
reinforcement for pillar a right lower |
|
| (11) |
3B4809220B |
b-pillar, inner S.SZ right |
|
| (11A) |
3B0810320B |
end plate b-pillar, inner right lower |
|
| (12) |
3B4810600D |
rip plate right inner |
|
| (13) |
3B4810608C |
reinforcement for side member right |
|
| (15) |
3B0809102F |
wheel housing with side member also use: right 7M0 804 198 |
|
| (16) |
3B0805086 |
insert plate for wheel housing right |
|
| (17) |
3B0805304C |
filler plate right |
|
| (17A) |
3B0805362E |
end plate right |
|
| (18) |
3B0805870B |
support right |
|
| (19) |
3B0809622A |
reinforcement for pillar a right upper |
|
| (2) |
3B0810232C |
outrigger, a-pillar right |
|
| (25) |
3B6801118 |
reinforcement for pillar a right inner |
|
| (25) |
3B6801117A |
reinforcement for pillar a left inner |
|
| (26) |
N 90408501 |
rivetted cap nut M8 |
|
| (3) |
3B0810179D |
a-pillar, inner left |
|
| (3) |
3B0810180D |
a-pillar, inner right |
|
| (4) |
3B5809429G |
side panel, inner left upper |
|
| (4) |
3B5809430G |
side panel, inner right upper |
|
| (5) |
3B5809261F |
reinforcement for pillar c left inner |
|
| (5) |
3B5809262E |
reinforcement for pillar c F >> 3B-2-173 904 right inner |
|
| (5) |
3B5809262F |
reinforcement for pillar c F 3B-2-173 905>> right inner |
|
| (8) |
3B5809405D |
side panel, inner left rear |
|
| (8) |
3B5809406D |
side panel, inner right rear |
|
| (9) |
3B5809642C |
water drain channel use if required: right rear 191 807 196 |
|
| - |
3B6809448 |
reinforcement b-pillar, inner right lower |
|
| - |
3B6809447 |
reinforcement b-pillar, inner left lower |
|
| - |
7M0804198 |
welded nut M8 |
|
| - |
3B6809228 |
reinforcement b-pillar, inner right upper |
|
| - |
8D0809154A |
wheel housing rear part right front |
|
| - |
3B6809227 |
reinforcement b-pillar, inner left upper |
|
| - |
8D0809153B |
wheel housing rear part left front |
|
| 1 |
3B0809203C |
reinforcement for pillar a left lower |
|
| 11 |
3B4809219B |
b-pillar, inner left |
|
| 11A |
3B0810319B |
end plate b-pillar, inner left lower |
|
| 12 |
3B4810599D |
rip plate left inner |
|
| 13 |
3B4810607C |
reinforcement for side member left |
|
| 15 |
3B0809101F |
wheel housing with side member left |
|
| 16 |
3B0805085 |
insert plate for wheel housing left |
|
| 17 |
3B0805303D |
filler plate left |
|
| 17A |
3B0805361E |
end plate left |
|
| 18 |
3B0805869B |
support left |
|
| 19 |
3B0809621A |
reinforcement for pillar a left upper |
|
| 2 |
3B0810231C |
outrigger, a-pillar left |
|
| 25 |
3B6801117 |
reinforcement for pillar a left inner |
|
| 26 |
N 90705701 |
rivetted cap nut M6/0,7-3-A |
|
| 7 |
3B0809237 |
threaded plate |
|
| 7A |
3B0809237A |
threaded plate |
|
| 9 |
3B5809641C |
water drain channel left rear |
|
| 9A |
191807196 |
plug 15 |
|
