Оригинальный
номер |
Название |
Заказ |
|
8D0941189 |
grommet for models with fog lamps |
|
| (11) |
7M0973119 |
flat contact housing sensor for headlight range control 6 pin front |
|
| (3) |
4B0971848 |
cable holder |
|
| (6) |
7M0973202 |
flat contact housing water level sender 2 pin |
|
| (6) |
1J0937723 |
flat contact housing with helper contact catch wiring harness for dash panel use if required: to be used for: 3 pin black 1J0 937 724 green violet |
|
| (6) |
1J0937724 |
flat contact housing with helper contact catch wiring harness for dash panel use if required: to be used for: 3 pin black 1J0 937 723 green violet |
|
| (8) |
4A0972243 |
round connector housing wiring harness for dash panel F >> 3B-WE118 144 F >> 3B-WP099 622 F >> 3B-WD080 964 3 pin |
|
| (8) |
1J0937724D |
flat contact housing with helper contact catch to be used for: use if required: F 3B-WE118 146>> F 3B-WP099 624>> F 3B-WD080 966>> 3 pin blue dark brown light pink orange 1J0 937 72 |
|
| (8) |
1J0937724B |
flat contact housing with helper contact catch to be used for: use if required: F 3B-WE118 146>> F 3B-WP099 624>> F 3B-WD080 966>> 3 pin red white khaki grey 1J0 937 723 B |
|
| (8) |
1J0937723D |
flat contact housing with helper contact catch to be used for: use if required: F 3B-WE118 146>> F 3B-WP099 624>> F 3B-WD080 966>> 3 pin blue dark brown light pink orange 1J0 937 72 |
|
| (8) |
1J0937723B |
flat contact housing with helper contact catch to be used for: use if required: F 3B-WE118 146>> F 3B-WP099 624>> F 3B-WD080 966>> 3 pin red white khaki grey 1J0 937 724 B |
|
| (8) |
4A0972241 |
round connector housing wiring harness for dash panel F >> 3B-WE118 144 F >> 3B-WP099 622 F >> 3B-WD080 964 3 pin |
|
| (9) |
3B0972840 |
plug 3,6X8,5 blue |
|
| (9) |
3B0972742C |
single wiring seal for wire cross section: 3,6X8,5 green 0,5-0,75 |
|
| (9) |
3B0972742B |
single wiring seal for wire cross section: 3,6X8,5 yellow 0,35 |
|
| 10 |
357972753 |
flat contact housing headlight range adjustment 3 pin |
|
| 11 |
813972923 |
flat contact housing with helper contact catch and grommet turn signal 2 pin |
|
| 4 |
8D0971871 |
grommet 51/15 |
|
| 5 |
8D0971897 |
cable holder |
|
| 6 |
1J0973722 |
flat contact housing with helper contact catch pump windscreen washer unit 2 pin black |
|
| 7 |
8D0971966 |
rd. connector sleeve housing headlight 5 pin |
|
| 8 |
. |
discontinued / replacement: wiring harness for dash panel 4A0 972 241 4A0 972 243 |
|
| 9 |
357972741 |
single wiring seal for wire cross section: 5,6X7,8 blue 1,0 |
|
