Оригинальный
номер |
Название |
Заказ |
| (20) |
N 90773701 |
corrugated pipe in coils of 5m order unit 5 17 |
|
| (28) |
191972724 |
flat contact housing coupling piece wiring harness for 4-speed automatic gearbox 8 pin |
|
| (38) |
1J0972752 |
flat contact housing coupling piece wiring harness for 4-speed automatic gearbox 2 pin |
|
| (45) |
1J0973332 |
flat contact housing for multi-function indicator 2 pin |
|
| - |
N 10311304 |
insulating tape 0,15X19X10000 |
|
| - |
N 90682601 |
corrugated pipe end piece 17 |
|
| - |
N 90682601 |
corrugated pipe end piece 17 |
|
| 11 |
701906231 |
flat contact housing connecting part central electrics 1 pin |
|
| 12 |
443906233 |
flat contact housing connecting part anti-knock sensor 3 pin |
|
| 13 |
037906240 |
flat contact housing connecting part bleeder valve 2 pin |
|
| 14 |
1H0906365 |
flat contact housing with gasket 68 pin |
|
| 15 |
1H0906375 |
gasket 16X105 |
|
| 16 |
357906376E |
protective cap 52/24/32 |
|
| 17 |
357906734B |
angled protective cap |
|
| 18 |
357907971B |
flat terminal pin housing connecter location: 1 pin U2,Y |
|
| 19 |
161937501B |
relay plate 9 pin |
|
| 21 |
N 90635517 |
corrugated pipe in coils of 5m order unit 5 for multi-function indicator 4,5 |
|
| 22 |
1H0971840 |
grommet 46/10,5 |
|
| 23 |
4B0971848 |
cable holder |
|
| 24 |
357971967 |
flat contact housing with helper contact catch connecter location: 12 pin G1 |
|
| 25 |
357971967A |
flat contact housing with helper contact catch connecter location: 12 pin G2 |
|
| 26 |
1J0972702 |
flat contact housing coupling piece wiring harness for dash panel 2 pin |
|
| 27 |
191972711 |
flat connector housing coupling piece dash panel insert 1 pin |
|
| 28 |
191972712 |
flat connector housing coupling piece harness for air conditioner 2 pin |
|
| 3 |
N 90773501 |
corrugated pipe in coils of 5m order unit 5 10 |
|
| 30 |
357972740D |
single wiring seal for wire cross section: 3,9X7,8 grey 0,5-1,0 |
|
| 31 |
357972741 |
single wiring seal for wire cross section: 5,6X7,8 blue 1,0 |
|
| 32 |
357972741B |
single wiring seal for wire cross section: 5,6X7,8 yellow orange 2,5 |
|
| 34 |
357972742C |
single wiring seal for wire cross section: 9,0X7,8 green 4,0 |
|
| 36 |
357972751 |
flat contact housing 1 pin |
|
| 38 |
357972752 |
flat contact housing connecting part switch for reversing light 2 pin |
|
| 39 |
357972753 |
flat contact housing connecting part distance sensor speed sender ignition transformer 3 pin |
|
| 40 |
357972754 |
flat contact housing connecting part air volume meter 4 pin |
|
| 42 |
357972771 |
flat contact housing connecting part starter 1 pin |
|
| 43 |
4B0972840 |
plug 4,0X7,8 white |
|
| 44 |
1H0973103 |
flat contact housing with gasket 28 pin |
|
| 46 |
3A0973204 |
flat contact housing connecting part lambda probe 4 pin |
|
| 7 |
N 90666101 |
cable tie 4,5X200 |
|
| 8 |
357903968 |
flat contact housing with helper contact catch connecter location: 10 pin F |
|
| 9 |
443906102B |
grommet 18X20,5 |
|
