Оригинальный
номер |
Название |
Заказ |
| (24) |
155919551 |
oil pressure gauge F >> 324 2181 150 5 BAR |
|
| (24) |
321919551A |
oil pressure gauge F 324 2181 151>> 326 2300 000 10 BAR |
|
| (9) |
113201337 |
seal fuel tank (plastic) 65X5,5X3 |
|
| - |
191915105M |
battery 63AH/300 |
|
| - |
000915105AA |
battery with charge state indicator, filled and charged 36AH/175A |
|
| - |
191915105E |
battery 45AH/220 |
|
| - |
191915105M |
battery 63AH/300A |
|
| 1 |
855915329 |
clamping strip for battery |
|
| 10 |
321919202 |
clock for console |
|
| 11 |
111919209A |
warning lamp green |
|
| 13 |
N 0177512 |
bulb W5/1,2W12V1,2W |
|
| 14 |
113919233B |
warning lamp for dual circuit brakes and handbrake F 326 2000 001>> rhd |
|
| 14 |
113919233B |
warning lamp for dual circuit brakes and handbrake F 325 2054 339>> 325 2300 000 |
|
| 15 |
171919305C |
cigarette lighter F 325 2016 680>> |
|
| 16B |
111919243 |
socket for bulb |
|
| 17 |
171919343A |
retaining sleeve for cigarette lighter F 325 2016 680>> |
|
| 19 |
481957397 |
socket for bulb F >> 326 2300 000 |
|
| 19A |
437919039 |
socket for bulb F 327 2000 001>> |
|
| 2 |
N 01155811 |
washer 8,4X15X1,6 |
|
| 20 |
N 0177512 |
bulb W5/1,2W12V1,2W |
|
| 21 |
084941521 |
switch for back-up light also use: 443 971 867 |
|
| 22 |
028919501A |
temperature sender 0-120C M10X1 1 pin black |
|
| 23 |
321919531A |
voltmeter also use: 437 919 039 N 017 751 2 |
|
| 23A |
437919039 |
socket for bulb |
|
| 23B |
N 0177512 |
bulb W5/1,2W12V1,2W |
|
| 25 |
411957117 |
knurled nut M4 |
|
| 26 |
111957397 |
socket for bulb |
|
| 27 |
N 0177222 |
bulb J12V2W |
|
| 3 |
N 01024016 |
hexagonal head bolt M8X20 |
|
| 4A |
443906231 |
flat terminal pin housing F 326 2129 200>> 2 pin |
|
| 4B |
447919141 |
protective cap flat terminal pin housing F 326 2129 200>> 2 pin |
|
| 5 |
021919081B |
oil pressure switch 0,15-0,45BAR 1 pin white |
|
| 5B |
321919095 |
strainer fuel tank (plastic) |
|
| 6 |
321919115 |
shackle clock 54MM 321 919 202 |
|
| 7 |
321919115C |
shackle voltmeter oil pressure gauge F >> 324 2298 613 42MM 321 919 531 A 155 919 551 321 919 551 A |
|
| 8 |
321919115D |
shackle voltmeter F 324 2298 614>> 49MM 321 919 531 A |
|
| 9 |
113919131A |
round seal fuel tank (sheet metal) 58X4 |
|
