Оригинальный
номер |
Название |
Заказ |
| (1) |
441505099F |
cross member for models with rear anti-roll bar |
|
| (10) |
4A0511512B |
trailing arm right |
|
| (14) |
443511224C |
bracket for toe adjustment right |
|
| (17A) |
443971826E |
cable holder right |
|
| (18A) |
4A0511330A |
support F 44-L-125 001>> right |
|
| (18A) |
4A0511329A |
support F 44-L-125 001>> left |
|
| (30) |
441199381E |
bonded rubber mounting F 44-L-000 001>>* |
|
| (31) |
N 90477701 |
washer F 44-L-000 001>>* 30X65X5 |
|
| (6) |
N 0104569 |
hexagonal head bolt M10X90 |
|
| - |
4A0511249 |
bearing only for: II |
|
| - |
4A0511247B |
bearing only for: I |
|
| - |
443511247D |
bearing only for: |
|
| 1 |
441505099A |
cross member F >> 4C-P-000 500* |
|
| 10 |
4A0511511B |
trailing arm left |
|
| 11 |
4D0511523C |
bearing |
|
| 12 |
N 0101913 |
hexagonal head bolt M12X1,5X95 |
|
| 13 |
N 90635001 |
hexagon nut, self-locking M12X1,5 |
|
| 14 |
443511223C |
bracket for toe adjustment left |
|
| 14A |
443505171F |
rubber mounting |
|
| 15 |
N 10118302 |
hexagonal head bolt M12X1,5X52 |
|
| 16 |
N 10106402 |
shouldered hex. nut, self-locking M12X1,5 |
|
| 16A |
N 90284003 |
hexagon nut, shouldered M12X1,5 |
|
| 17 |
443511531C |
plug |
|
| 17A |
443971826D |
cable holder left |
|
| 17B |
N 0138671 |
hex.hd. thread cutting bolt AM5X10 |
|
| 18A |
443511329B |
support F >> 44-L-125 000* |
|
| 2 |
441505120A |
retainer I |
|
| 20 |
443511277B |
bearing |
|
| 21 |
N 10057502 |
hexagonal head bolt M10X70 |
|
| 22 |
N 0230047 |
shouldered hex. nut, self-locking AM10 |
|
| 23 |
443511341A |
washer |
|
| 23A |
4A0511341A |
washer F 4C-P-000 001>> |
|
| 23A |
443511341F |
washer F >> 4C-N-010 000 |
|
| 23AB |
443511341G |
washer F >> 4C-N-010 000 |
|
| 26 |
N 0211955 |
hexagon nut, self-locking M10 |
|
| 26A |
823199347 |
washer 40X2,5 |
|
| 27 |
443525325B |
mounting |
|
| 28 |
N 0115608 |
washer 10,5X18X1,6 |
|
| 29 |
N 0199113 |
allen key head bolt M10X28 |
|
| 2A |
441505253 |
end plate |
|
| 2B |
N 0447273 |
allen key head bolt M10X16 |
|
| 3 |
441505127 |
retainer II |
|
| 30 |
183199381A |
bonded rubber mounting F >> 44-K-150 000* |
|
| 31 |
N 90337102 |
washer F >> 44-K-150 000* 10,6X65X5 |
|
| 32 |
N 10131203 |
hexagonal head bolt M10X105X32 |
|
| 33 |
N 0230047 |
shouldered hex. nut, self-locking AM10 |
|
| 34 |
N 10298501 |
hexagonal head bolt M14X1,5X105 |
|
| 35 |
N 0101977 |
bolt, hexagon head self-locking M14X1,5X65 |
|
| 36 |
441018965B |
retainer |
|
| 37 |
441599141A |
brace F 44-L-000 001>>* |
|
| 38 |
441599247 |
plate F 44-L-000 001>>* |
|
| 39 |
N 01023911 |
hexagonal head bolt M8X18 |
|
| 4 |
161253311 |
bracket for exhaust pipe |
|
| 40 |
N 90285601 |
hexagonal nut M10 |
|
| 5 |
443505145A |
bearing |
|
| 6 |
N 0104607 |
hexagonal head bolt M10X60 |
|
| 6A |
N 0116726 |
washer B10,5X30X2,5 |
|
| 7 |
N 0211955 |
hexagon nut, self-locking M10 |
|
| 8 |
431253149B |
stop buffer |
|
| 9 |
N 0402495 |
hexagonal head bolt M10X40 |
|
