Оригинальный
номер |
Название |
Заказ |
| (17) |
8A0804484 |
support plate right |
|
| (18) |
8A0804483 |
support plate left |
|
| (31) |
8A0804102 |
bracket for strap fuel tank right |
|
| (32) |
8A0803291 |
cross member for floor left front |
|
| (40) |
8D0813545 |
bracket for child seat -isofix- |
|
| (5) |
8D0803421A |
wheel housingliner left rear |
|
| (7) |
8A0803892A |
reinforcement seat belts right |
|
| (8) |
8D0802088E |
floor plate for models with activated charcoal canister rear |
|
| - |
000800981 |
sheet metal plate 200X1500X0,8 |
|
| - |
000800981C |
sheet metal plate 800X1500X0,8 |
|
| - |
000800981B |
sheet metal plate 500X1500X0,8 |
|
| - |
000800981A |
sheet metal plate 300X1500X0,8 |
|
| - |
443803389C |
damping strip 100X75X4 |
|
| 1 |
8D0803093K |
floor plate center |
|
| 10 |
8D0802226A |
mounting for hinged backrest right |
|
| 12 |
8A0804715C |
reinforcement inner |
|
| 12A |
8D0803899 |
bolt for spare wheel mounting M8X80 |
|
| 13 |
6X0803959 |
cover for sender unit |
|
| 14 |
321803963 |
seal |
|
| 16 |
N 90286703 |
hex. nut, self-locking with washer M6 |
|
| 2 |
N 90231601 |
weld pin order unit 100 FD-5X25 |
|
| 30 |
8D0804893 |
console |
|
| 31 |
8A0804101 |
bracket for strap fuel tank left |
|
| 33 |
8A0804121A |
bracket for strap fuel tank |
|
| 40 |
8D0813546A |
bracket for child seat -isofix- |
|
| 41 |
8L0887233 |
fitting sleeve - child s seat -isofix- |
|
| 42 |
8L0837453 |
torx socket head combi-bolt M8X27-H-V |
|
| 5 |
8D0803422A |
wheel housingliner right rear |
|
| 7 |
8A0803891A |
reinforcement seat belts left |
|
| 8 |
8D0802088A |
floor plate rear |
|
| 9 |
8D0802225A |
mounting for hinged backrest left |
|
