Оригинальный
номер |
Название |
Заказ |
| (1) |
8D9809839D |
sub-part - side panel frame a-pillar left |
|
| (1) |
8D9809840D |
sub-part - side panel frame a-pillar right |
|
| (1/2) |
8D9809606 |
side panel right outer |
|
| (10) |
8D9809302B |
console wheel housing right rear |
|
| (11) |
8D9809412B |
wheel housingliner right outer |
|
| (12) |
8D9809454A |
insert plate for side panel right rear |
|
| (13) |
8D9813382F |
mounting sheet tie-down eye right rear |
|
| (13) |
8D9813381A |
mounting sheet tie-down eye for models with detachable towing attachment (ball type) left rear |
|
| (13) |
8D9813382A |
mounting sheet tie-down eye for models with detachable towing attachment (ball type) right rear |
|
| (14) |
8D0810172D |
wheel housing-plastic material right rear |
|
| (3) |
8D9809834E |
sub-part - side panel frame/roof cross member for vehicles with roof rails right |
|
| (3) |
8D9809833E |
sub-part - side panel frame/roof cross member for vehicles with roof rails left |
|
| (4) |
8D9809847D |
sub-part - side panel frame side member use if required: left |
|
| (4) |
8D9809848D |
sub-part - side panel frame side member use if required: right |
|
| (5) |
8D9809105L |
side panel frame left rear |
|
| (5) |
8D9810086 |
side panel frame right rear |
|
| (6) |
8D9810182J |
side panel frame right rear |
|
| (7) |
8D5810224B |
b-pillar, inner right |
|
| (7) |
8D5810223B |
b-pillar, inner left |
|
| (8) |
8D9810180B |
a-pillar, inner right |
|
| (8A) |
8D0810209A |
hinge reinforcement left lower |
|
| (8A) |
8D0810210A |
hinge reinforcement right lower |
|
| (9) |
8D9809290 |
d-pillar right lower |
|
| - |
N 10009104 |
hexagon head bolt (combi) M6X12 |
|
| - |
8D9809263C |
reinforcement for pillar c left lower |
|
| - |
8D0809237 |
threaded plate |
|
| - |
8D9809264C |
reinforcement for pillar c right lower |
|
| 1/2 |
8D9809605 |
side panel left outer |
|
| 10 |
8D9809301B |
console wheel housing left rear |
|
| 11 |
8D9809411B |
wheel housingliner left outer |
|
| 12 |
8D9809453A |
insert plate for side panel left rear |
|
| 13 |
8D9813381E |
mounting sheet tie-down eye left rear |
|
| 14 |
8D0810171D |
wheel housing-plastic material left rear |
|
| 15 |
N 90775001 |
torx socket head panel screw 4,8X16 |
|
| 16 |
N 90821401 |
expanding nut D4,8 |
|
| 6 |
8D9810181J |
side panel frame left rear |
|
| 8 |
8D9810179B |
a-pillar, inner left |
|
| 9 |
8D9809289 |
d-pillar left lower |
|
