Оригинальный
номер |
Название |
Заказ |
| (1) |
859407152A |
track control arm right front |
|
| (1) |
893407148C |
track control arm F 85-D-900 001>> 85-K-020 000 |
|
| (1) |
857407147B |
track control arm F 85-L-000 001>> |
|
| (1) |
857407148B |
track control arm F 85-L-000 001>> |
|
| (1) |
859407151A |
track control arm left front |
|
| (11) |
859407271 |
drive shaft with constant velocity joints |
|
| (11) |
857407272C |
drive shaft with constant velocity joints for models with anti-lock brake system -abs- right front |
|
| (11) |
857407272A |
drive shaft with constant velocity joints right front |
|
| (11) |
857407271C |
drive shaft with constant velocity joints for models with anti-lock brake system -abs- left front |
|
| (2) |
857407365F |
guide joint F 85-L-000 001>> |
|
| (2) |
859407365A |
guide joint left/right |
|
| (2) |
857407366F |
guide joint F 85-L-000 001>> |
|
| (2) |
857407366E |
guide joint also use: right front |
|
| (23) |
N 90280401 |
12-point head bolt M10X55 |
|
| (24) |
443407357 |
spacer plate F 85-K-000 069>> |
|
| (25) |
857407721A |
heat protection plate |
|
| (26) |
N 01023911 |
hexagonal head bolt M8X18 |
|
| (27) |
N 01155811 |
washer 8,4X15X1,6 |
|
| (28) |
859407613 |
wheel hub |
|
| (29) |
443498625E |
wheel bearing with mounting parts F 85-G-900 001>> 82MM |
|
| (3) |
857407175 |
lock plate |
|
| (30) |
N 10089101 |
securing ring F 85-G-900 001>> 82X2,5 |
|
| (33) |
N 0347784 |
hexagonal head bolt M10X50X24 |
|
| (36) |
443498203A |
joint protective boot with assembly items and grease for models with anti-lock brake system -abs- outer |
|
| (37) |
443498099AX |
wheel shaft, outer with joint, rotor and assembly parts for models with anti-lock brake system -abs- |
|
| (6) |
N 0111896 |
hexagon nut, self-locking M10X1 |
|
| (7) |
893407181 |
bonded rubber mounting |
|
| (7) |
8A0407181 |
bonded rubber mounting F 85-D-900 001>> |
|
| - |
431407727 |
spacer tube |
|
| - |
859407683A |
radius rod |
|
| - |
859407465A |
stabilizer |
|
| - |
859407185C |
bush |
|
| - |
859407199 |
adjusting piece |
|
| - |
N 0104553 |
hexagonal head bolt M10X55 |
|
| - |
N 10286102 |
shouldered hex. nut, self-locking M10 |
|
| - |
859407683A |
radius rod |
|
| - |
N 10277903 |
hexagonal head bolt M10X50 |
|
| - |
331407196 |
plug |
|
| - |
857411309D |
stabilizer front |
|
| 1 |
893407147C |
track control arm F 85-D-900 001>> 85-K-020 000 |
|
| 10 |
N 10286102 |
shouldered hex. nut, self-locking M10 |
|
| 11 |
857407271A |
drive shaft with constant velocity joints left front |
|
| 13 |
803407292 |
hose clip 70 |
|
| 15 |
113501159B |
terminal 34 |
|
| 16 |
N 90208001 |
terminal 103X9X1 |
|
| 17 |
431407297A |
securing ring |
|
| 2 |
857407365E |
guide joint also use: left front |
|
| 21 |
8D0407309A |
sealing washer 94MM |
|
| 22 |
N 0123741 |
securing ring F 85-E-900 701>>* 28X1,5 |
|
| 23 |
N 90668201 |
bolt, with multi-spilne socket head M10X48 |
|
| 24 |
431407357B |
spacer plate F >> 85-K-000 068* |
|
| 25 |
857407721 |
heat protection plate |
|
| 26 |
N 01034510 |
hexagonal head bolt M8X45 |
|
| 27 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 28 |
447407615A |
wheel hub |
|
| 29 |
443498625 |
wheel bearing with mounting parts F >> 85-F-901 500 75,07MM |
|
| 3 |
811407175A |
lock plate |
|
| 30 |
N 0122981 |
securing ring F >> 85-F-901 500 75X2,5 |
|
| 31 |
803407277A |
washer |
|
| 32 |
803407643A |
lock nut M22X1,5 |
|
| 33 |
N 0104457 |
hexagonal head bolt M10X45X20 |
|
| 34 |
N 10286102 |
shouldered hex. nut, self-locking M10 |
|
| 35 |
G 052133A3 |
high temperature grease 120G |
|
| 36 |
431498203D |
joint protective boot with assembly items and grease outer |
|
| 37 |
183498099A |
wheel shaft outer with joint and attachment parts |
|
| 38 |
443498201B |
joint protective boot with assembly items and grease inner |
|
| 39 |
431498103C |
constant velocity joint with boot, attachment parts and grease inner |
|
| 4 |
N 0102754 |
hexagonal head bolt M10X35 |
|
| 5 |
N 01152711 |
washer A10,5X21X2 |
|
| 6 |
N 10286102 |
shouldered hex. nut, self-locking M10 |
|
| 7 |
8A0407181 |
bonded rubber mounting F >> 85-C-902 000 |
|
| 8 |
N 90556902 |
hexagonal head bolt M10X75 |
|
| 9 |
N 01152711 |
washer A10,5X21X2 |
|
