Оригинальный
номер |
Название |
Заказ |
| (21) |
016311287A |
securing ring 1,7 |
|
| (21) |
016311287B |
securing ring 43X1,75 |
|
| (22) |
088311287B |
securing ring 1,75 |
|
| (29) |
088311317B |
securing ring 35,2X1,56 |
|
| (29) |
088311317C |
securing ring 35,2X1,62 |
|
| (30) |
016311327B |
securing ring 36X1,6 |
|
| (30) |
016311327A |
securing ring 36X1,55 |
|
| (32) |
016311353C |
change gear 5-speed |
|
| (37) |
N 90258201 |
bolt, hex. hd. (combi.) self-locking M10X22 |
|
| (39) |
016311391A |
adjusting washer 1,4 |
|
| (39) |
016311391B |
adjusting washer 1,7 |
|
| (39) |
016311391C |
adjusting washer 2 |
|
| (39) |
016311391D |
adjusting washer 2,3 |
|
| (40) |
088311391E |
compensation washer 0,65 |
|
| (40) |
088311391D |
compensation washer 0,4 |
|
| (40) |
088311391G |
compensation washer 1,15 |
|
| (40) |
088311391B |
compensation washer 0,3 |
|
| (40) |
088311391C |
compensation washer 0,35 |
|
| (40) |
088311391A |
compensation washer 0,25 |
|
| (40) |
088311391F |
compensation washer 0,9 |
|
| (41) |
016311393B |
compensation washer 0,3 |
|
| (41) |
016311393H |
compensation washer 0,69 |
|
| (41) |
016311393G |
compensation washer 0,45 |
|
| (41) |
016311393F |
compensation washer 0,42 |
|
| (41) |
016311393E |
compensation washer 0,39 |
|
| (41) |
016311393D |
compensation washer 0,36 |
|
| (41) |
016311393C |
compensation washer 0,33 |
|
| (41) |
016311393K |
compensation washer 1,17 |
|
| (41) |
016311393A |
compensation washer 0,27 |
|
| (41) |
016311393L |
compensation washer 1,41 |
|
| (41) |
016311393J |
compensation washer 0,93 |
|
| (43) |
N 90060602 |
securing ring A27X1,4 |
|
| (43) |
N 90060603 |
securing ring A27X1,45 |
|
| (45) |
N 90060802 |
securing ring A68X2,9 |
|
| (9) |
016311159D |
gear 5-speed |
|
| - |
034105313A |
needle bearing - BK15X24X26 |
|
| - |
016311344 |
securing ring 33,9X3 |
|
| 1 |
016311105AP |
propshaft also use: Z=10+16 |
|
| 10 |
016311192A |
clutch hub 5-speed |
|
| 11 |
016311207B |
needle bearing - K39X44X25,8 |
|
| 12 |
016311213H |
needle cage 37,5X42X27,3 |
|
| 13 |
016311220E |
taper roller bearing |
|
| 14 |
016311229A |
needle bearing - K43X48X26,8 |
|
| 15 |
016311239E |
synchronizing hub with locking collar 1./2.gear |
|
| 16 |
088311245 |
locking piece 3./4.gear |
|
| 17 |
016311246 |
locking piece |
|
| 18 |
016311257 |
change gear 1.gear |
|
| 19 |
016311271 |
change gear 2.gear |
|
| 2 |
016311113B |
seal |
|
| 20 |
088311285A |
change gear 3.gear |
|
| 21 |
016311287 |
securing ring 43X1,65 |
|
| 22 |
088311287 |
securing ring 1,65 |
|
| 23 |
014311295E |
synchronizer ring 5-speed |
|
| 24 |
016311295 |
synchronizer ring 1st-4th gear |
|
| 25 |
088311301B |
synchronizing hub with locking collar 3./4.gear |
|
| 26 |
014311311C |
spring 5-speed |
|
| 27 |
088311311D |
spring 1st-4th gear |
|
| 28 |
088311313 |
locking piece 1./2.gear |
|
| 29 |
088311317 |
securing ring 35,2X1,50 |
|
| 3 |
016311115 |
needle bearing - K37,5X42X31,3 |
|
| 30 |
016311327 |
securing ring 36X1,5 |
|
| 31 |
088311351A |
change gear 4-speed |
|
| 32 |
016311353B |
change gear 5-speed |
|
| 33 |
N 90060701 |
securing ring A27X1,9 |
|
| 36 |
016311373A |
washer |
|
| 38 |
016311375B |
radial roller bearing 31,7X76,2X29,3 |
|
| 39 |
016311391 |
adjusting washer 1,1 |
|
| 4 |
016311116B |
needle bearing - |
|
| 40 |
088311391 |
compensation washer 0,2 |
|
| 41 |
016311393 |
compensation washer 0,24 |
|
| 42 |
016311427 |
cylinder roller bearing 27,2X62X17 |
|
| 43 |
N 90060601 |
securing ring A27X1,35 |
|
| 44 |
016311445 |
ball bearing 25X68X18 |
|
| 45 |
N 90060801 |
securing ring A68X2,83 |
|
| 46 |
016311449 |
baffle plate |
|
| 47 |
016311519B |
reverse gear idler spindle |
|
| 48 |
016311529B |
reverse gear |
|
| 5 |
088311123 |
needle sleeve 30X41X21 |
|
| 50 |
016311853B |
retaining plate |
|
| 51 |
016311859C |
pressure spring |
|
| 52 |
016311861C |
spring clasp |
|
| 53 |
016311839C |
synchronizer ring |
|
| 54 |
088301291A |
bolt, hex. hd. with shoulder and shaft M8X11,5/11X4,5 |
|
| 8 |
088311155A |
thrust washer |
|
| 9 |
016311159C |
gear 5-speed |
|
