Оригинальный
номер |
Название |
Заказ |
|
431819823 01C |
satin black |
|
|
321819645 01C |
satin black |
|
| (19) |
432819303B |
intake shaft rhd |
|
| (31) |
432819371A |
water hose rhd |
|
| (35) |
056919367 |
thermal switch with: plastic housing also use: 17/25C |
|
| (41) |
321819645 |
mounting clip F >> 43-C-020 265* |
|
| (58) |
444819015 |
electric fan motor rhd |
|
| (7) |
444819095A |
housing half also use: left rhd |
|
| - |
000979133B |
1 set: single wires (high temperature resistant) each with 2 contacts, qty. 5 per bag order unit 5 possible replacement 1,0 |
|
| - |
N 0441001 |
panel screw shorten to: ST4,2X45-C |
|
| - |
000979133 |
1 set: single wires each with 2 contacts, qty. 5 per bag order unit 5 flat contact 1,0 |
|
| 10 |
431819211A |
gasket |
|
| 11 |
431819225 |
gasket 1360MM |
|
| 12 |
432819269A |
lever for locking flap rhd |
|
| 13 |
443819279C |
control flap |
|
| 18 |
431819296 |
connecting rod |
|
| 19 |
4A1819303A |
intake shaft lhd |
|
| 2 |
443819030 |
heat exchanger |
|
| 20 |
N 0139594 |
oval head panel screw 3,5X16 |
|
| 21 |
N 0115213 |
washer A3,7X8X0,5 |
|
| 23 |
431819307B |
hose lhd |
|
| 24 |
431819309B |
distance piece lhd |
|
| 25 |
431819311 |
grommet |
|
| 26 |
N 0124251 |
securing ring 25X1,2 |
|
| 29 |
4A2819349 |
cover rhd |
|
| 30 |
N 0139649 |
oval head panel screw ST4,2X16-C |
|
| 31 |
431819371E |
water hose lhd |
|
| 32 |
444819373C |
water hose rhd |
|
| 33 |
444819373C |
water hose rhd |
|
| 34 |
N 90561801 |
pipe clip AL16-28 |
|
| 38 |
N 10258101 |
pipe clip AL23-35 |
|
| 39 |
4D0971911 |
grommet 17/8,5 |
|
| 4 |
431819067 |
washer lhd |
|
| 41 |
431819645A |
clip F 43-C-020 266>>* |
|
| 43 |
431819645 |
clip |
|
| 44 |
823819679 |
clips |
|
| 45 |
431819823 |
knob |
|
| 48 |
4A0819849D |
grommet |
|
| 49 |
N 0139755 |
oval head panel screw ST4,8X19 |
|
| 5 |
321819059 |
clips |
|
| 50 |
N 0116653 |
washer 5,3X15X1,6 |
|
| 51 |
N 0154581 |
snap nut B4,8X19X16 |
|
| 52 |
431819809A |
heater valve |
|
| 53 |
431819887 |
tensioning strap |
|
| 54 |
431819885 |
tensioning strap |
|
| 55 |
N 90030301 |
panel screw B4,2X35 |
|
| 57 |
N 0177222 |
bulb J12V2W |
|
| 58 |
431959101C |
blower motor with fan also use: lhd |
|
| 59 |
141951253B |
relay |
|
| 61 |
N 90015101 |
clamping washer B-5X11,4 |
|
| 62 |
111919243 |
socket for bulb |
|
| 7 |
443819095A |
housing half also use: left lhd |
|
| 8 |
443819096A |
housing half also use: right |
|
