Оригинальный
номер |
Название |
Заказ |
|
8N8827280A 01C |
satin black |
|
|
8N8827519A 01C |
satin black |
|
|
8N8827279A 01C |
satin black |
|
| (1) |
8N8827023C |
tailgate / boot lid for vehicles with spoiler |
|
| (14) |
447857670 |
foam packing (self-adhesive) shorten to: 280X12X7MM |
|
| (18) |
8N0827249A |
stop buffer, adjustable |
|
| (2) |
8N8827300C |
bonnet hinge right |
|
| (20) |
6X0827951A |
plug use if required: 7,5/25 |
|
| (21) |
8N8827531B |
bonnet lock cable |
|
| (6) |
8N8827280A |
cover cap bonnet hinge right |
|
| (7) |
8N8827552B |
gas-filled strut for vehicles with spoiler left/right |
|
| - |
8N0827771 |
protective foil (self-adhesivel) adapt with workshop equipment left/right |
|
| - |
N 90648101 |
rivetted cap nut M6/0,7-3B |
|
| - |
1J0957818C |
cable tie 4,5X162 |
|
| - |
N 0209022 |
cable tie 3,6X246 |
|
| - |
1E0955787 |
clip bonnet lock cable |
|
| - |
8N0827257 |
covering rear center |
|
| 1 |
8N8827023D |
tailgate / boot lid |
|
| 10 |
8N0827507B |
closure plate |
|
| 11 |
N 90684701 |
fillister head bolt (combi.) M6X20-CH-S11 |
|
| 12 |
8N0827505C |
flap - lock inner |
|
| 13 |
4B5962115A |
throttle control element |
|
| 15 |
N 90288502 |
oval head panel screw 5X23MM |
|
| 17 |
N 90691501 |
bolt, torx socket head M6X35 |
|
| 17A |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 19 |
N 10444001 |
cup rivet AK4X11 |
|
| 2 |
8N8827299C |
bonnet hinge left |
|
| 22 |
8N8827587 |
retaining bracket bowden cable center |
|
| 23 |
N 90175203 |
hexagon nut, shouldered M6 |
|
| 24 |
8N8827519A |
covering striker plate |
|
| 25 |
8N8827669 |
gasket for flap, rear upper |
|
| 3 |
N 90786502 |
hexagon head bolt (combi) M8X20-U-S1 |
|
| 5 |
N 90511503 |
hex. nut with washer M8 |
|
| 6 |
8N8827279A |
cover cap bonnet hinge left |
|
| 8 |
895827439B |
ball pin |
|
| 9 |
8N8827705C |
gasket |
|
