Оригинальный
номер |
Название |
Заказ |
|
8N0858208 01C |
satin black |
|
|
8N1857003A 24A |
soul (black) |
|
|
8N2857003A 24A |
soul (black) |
|
|
8N0857086 6PS |
soul (black) |
|
|
8N0857085 6PS |
soul (black) |
|
|
8N0858207 01C |
satin black |
|
| (1) |
8N2857003A |
dashboard with air duct rhd |
|
| (13) |
8N2858435 |
retaining panel shelf/stowage compartment (drivers side) rhd |
|
| (26) |
8N0858388 |
securing plate right |
|
| (27) |
8N0857086 |
cover cap right |
|
| 1 |
8N1857003A |
dashboard with air duct lhd |
|
| 10 |
8N0858207 |
cover cap dashboard left front |
|
| 11 |
8N0858208 |
cover cap dashboard right front |
|
| 13 |
8N1858435 |
retaining panel shelf/stowage compartment (drivers side) lhd |
|
| 14 |
N 90356203 |
snap nut M5X17X17 |
|
| 15 |
N 90729001 |
shouldered bolt M5X16-SP |
|
| 16 |
4A0857327B |
clips |
|
| 17 |
N 90471802 |
hexagonal head bolt M8X18 |
|
| 18 |
N 90729001 |
shouldered bolt M5X16-SP |
|
| 19 |
N 90728701 |
torx socket fillister head bolt (combi) M5X16-E-Z1 |
|
| 20 |
N 90356203 |
snap nut M5X17X17 |
|
| 25 |
N 90729001 |
shouldered bolt M5X16-SP |
|
| 26 |
8N0858387 |
securing plate left |
|
| 27 |
8N0857085 |
cover cap left |
|
| 29 |
N 90729001 |
shouldered bolt M5X16-SP |
|
| 3 |
N 90732101 |
torx socket head panel screw 4X16-Q |
|
| 32 |
N 0195334 |
hexagon head bolt c/w shoulder M8X20 |
|
| 33 |
8N7810201 |
support a-pillar, inner left |
|
| 34 |
8N7810202 |
support a-pillar, inner right |
|
| 35 |
443845643C |
hexagonal head bolt M8X28 |
|
| 36 |
N 90674202 |
hexagonal head bolt M8X45 |
|
| 37 |
N 90008602 |
washer 12X25X2,8 |
|
| 38 |
N 90074401 |
hexagon nut, self-locking M8 |
|
| 8 |
8L0857225 |
intermediate layer cross member center |
|
