Оригинальный
номер |
Название |
Заказ |
| (1) |
8N0199313E |
sub-frame with rubber mounting |
|
| (16) |
1J0199117AK |
console left |
|
| (2) |
8N0199282C |
bonded rubber mounting upper |
|
| (2) |
8N0199282D |
bonded rubber mounting lower |
|
| (21) |
N 90597002 |
hexagon head bolt c/w shoulder M10X70-SW16 |
|
| (25) |
8N0199851 |
support rear |
|
| (29) |
8N0199521A |
cross tube |
|
| (5) |
1J0199262CL |
engine mounting right |
|
| (7) |
8N0199588B |
support right |
|
| (9) |
8N0199555C |
gearbox mounting hydro-mounting left |
|
| - |
8N0199399 |
lock washer |
|
| 1 |
8N7199313F |
sub-frame with rubber mounting |
|
| 10 |
N 90596902 |
bolt, hex. hd. with shoulder, self-locking M10X55-SW16KL |
|
| 11 |
N 10155901 |
hexagon head bolt c/w shoulder M8X20 |
|
| 12 |
038199207H |
support right |
|
| 13 |
N 90712401 |
hexagon head bolt c/w shoulder M10X85 |
|
| 14 |
N 10209801 |
hexagonal head bolt BM10X112 |
|
| 15 |
N 10209603 |
hexagon head bolt c/w shoulder M12X1,5X65 |
|
| 18 |
1J0199359D |
support for transmission |
|
| 19 |
N 0197002 |
hexagon head bolt c/w shoulder M8X30 |
|
| 20 |
N 01508311 |
hexagon nut, shouldered M8 |
|
| 24 |
N 10209603 |
hexagon head bolt c/w shoulder M12X1,5X65 |
|
| 26 |
N 10268302 |
hexagon head bolt c/w shoulder AM8X45 |
|
| 27 |
N 10246605 |
hexagon head bolt c/w shoulder M10X30-SW16 |
|
| 28 |
N 90597001 |
hexagon head bolt c/w shoulder M10X70-SW16 |
|
| 3 |
N 90752801 |
hexagon head bolt (combi) M14X1,5X63 |
|
| 34 |
8N7199401 |
brace front and rear |
|
| 35 |
N 0195024 |
hexagon head bolt c/w shoulder also use: M8X25 |
|
| 4 |
N 90734901 |
hexagon head bolt (combi) M14X1,5X95 |
|
| 6 |
N 90596902 |
bolt, hex. hd. with shoulder, self-locking M10X55-SW16KL |
|
| 8 |
N 10155901 |
hexagon head bolt c/w shoulder M8X20 |
|
