Оригинальный
номер |
Название |
Заказ |
| (11) |
N 01224110 |
spring washer B8X15X0,8 |
|
| (17) |
N 0102228 |
hexagonal head bolt M6X22 |
|
| (30) |
056109572 |
adjusting washer 3,85 |
|
| (30) |
056109571 |
adjusting washer 3,8 |
|
| (30) |
056109569 |
adjusting washer 3,7 |
|
| (30) |
056109568 |
adjusting washer 3,65 |
|
| (30) |
056109567 |
adjusting washer 3,6 |
|
| (30) |
056109566 |
adjusting washer 3,55 |
|
| (30) |
056109565 |
adjusting washer 3,5 |
|
| (30) |
056109564 |
adjusting washer 3,45 |
|
| (30) |
056109562 |
adjusting washer 3,35 |
|
| (30) |
056109570 |
adjusting washer 3,75 |
|
| (30) |
056109573 |
adjusting washer 3,9 |
|
| (30) |
056109574 |
adjusting washer 3,95 |
|
| (30) |
056109580 |
adjusting washer 4,25 |
|
| (30) |
056109579 |
adjusting washer 4,2 |
|
| (30) |
056109578 |
adjusting washer 4,15 |
|
| (30) |
056109577 |
adjusting washer 4,1 |
|
| (30) |
056109563 |
adjusting washer 3,4 |
|
| (30) |
056109576 |
adjusting washer 4,05 |
|
| (30) |
056109575 |
adjusting washer 4 |
|
| (36) |
049109641A |
spring disc upper |
|
| (37) |
113109651A |
cotter, split |
|
| (39) |
056103652 |
camshaft bearing shell for reconditioned cylinder head only 26 |
|
| - |
056198119 |
repair kit for toothed belt with tensioning roller use if required: |
|
| - |
N 90296401 |
stud M10X40/15 |
|
| - |
049109188B |
sealing strip |
|
| 1 |
049109101C |
camshaft |
|
| 10 |
N 01021226 |
hexagonal head bolt M6X12 |
|
| 11 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 11A |
056109143 |
washer 12,5X28X6 |
|
| 12 |
049109166 |
stud |
|
| 13 |
056129669B |
grommet |
|
| 14 |
049109207 |
shouldered nut with socket M6 |
|
| 15 |
N 90053401 |
t-head screw AM6X35 |
|
| 16 |
049109175 |
toothed belt cover lower |
|
| 17 |
N 0147053 |
allen key head bolt M6X25 |
|
| 18 |
N 01100624 |
hexagonal nut M6 |
|
| 23 |
026109243L |
tensioning roller also use: |
|
| 24 |
056103399 |
stud M10X53 |
|
| 25 |
N 0122314 |
spring washer A10X18X0,8 |
|
| 26 |
N 0111337 |
hexagonal nut M10 |
|
| 27 |
049109291A |
plug |
|
| 28 |
056109311A |
cam follower |
|
| 3 |
N 0127082 |
woodruff key 4X5 |
|
| 30 |
056109561 |
adjusting washer 3,3 |
|
| 31 |
049109601K |
intake valve also use: 98,7 |
|
| 32 |
049109611F |
exhaust valve also use: 98,5 |
|
| 33 |
078109623A |
spring - valve outer |
|
| 34 |
056109629A |
spring disc lower |
|
| 35 |
078109633A |
spring - valve inner |
|
| 36 |
056109641A |
spring disc upper |
|
| 37 |
056109651 |
cotter, split |
|
| 38 |
026109675 |
seal - valve stem 8MM |
|
| 39 |
056103651 |
camshaft bearing shell (undersize) for reconditioned cylinder head only 25,75 |
|
| 4 |
049109111C |
toothed belt pulley |
|
| 5 |
N 0101371 |
hexagonal head bolt M12X1,5X35 |
|
| 6 |
056109119A |
toothed belt Z=121 |
|
| 7 |
055109107B |
toothed belt cover also use: |
|
| 8 |
N 0200271 |
plug A15X1 |
|
| 9 |
055109127A |
cover panel also use: |
|
| 9A |
049109271 |
base J20X53 |
|
