Оригинальный
номер |
Название |
Заказ |
| (1) |
078133837G |
air cleaner F 8B-P-004 635>> |
|
| (1) |
078133837F |
air cleaner |
|
| (10) |
078133471A |
air volume meter F 8B-P-004 635>> |
|
| (10) |
078133471AX |
air volume meter F 8B-P-004 635>> |
|
| (18) |
078133357H |
intake air duct |
|
| (19) |
8A0129627F |
intake hose F 8B-P-004 635>> |
|
| (19) |
8A0129627F |
intake hose |
|
| (20) |
N 0245083 |
pipe clip F 8B-P-004 635>> LA80-100 |
|
| (20) |
N 0245083 |
pipe clip LA80-100 |
|
| (3) |
078129797 |
sealing clip |
|
| - |
078129949 |
gasket |
|
| - |
078133364 |
rubber bush |
|
| 1 |
078133837G |
air cleaner F >> 8B-P-004 634 |
|
| 10 |
054133471A |
air volume meter F >> 8B-P-004 634 |
|
| 11 |
034133485 |
gasket |
|
| 12 |
N 01021710 |
hexagonal head bolt M6X20 |
|
| 13 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 14 |
054129777B |
plug F >> 8B-P-004 634 blue |
|
| 15 |
055129669 |
rubber mounting 17/11,8 |
|
| 16 |
034133861 |
sleeve |
|
| 17 |
N 0102186 |
hexagonal head bolt M6X25 |
|
| 19 |
8A0129627 |
intake hose F >> 8B-P-004 634 |
|
| 2 |
191129620 |
air cleaner element |
|
| 20 |
N 0245223 |
pipe clip F >> 8B-P-004 634 LA60-80 |
|
| 21 |
N 0245183 |
pipe clip AL70-90 |
|
| 22 |
N 0245044 |
pipe clip F >> 8B-P-001 476 LC40-60 |
|
| 23 |
027129627E |
warm air hose shorten to: F >> 8B-P-001 476 50,8X550MM |
|
| 24 |
078103221B |
breather hose left |
|
| 25 |
078103224A |
breather hose right |
|
| 26 |
078103939 |
covering F >> 8B-N-004 000* |
|
| 3 |
191129797A |
sealing clip MANN+HUMMEL |
|
| 4 |
N 0115501 |
washer B6,5X21X2 |
|
| 5 |
N 01100624 |
hexagonal nut M6 |
|
| 6 |
034133861 |
sleeve |
|
| 7 |
431129669 |
grommet |
|
| 8 |
N 01024222 |
hexagonal head bolt M8X25 |
|
| 9 |
N 90477201 |
washer B8,4X24X2 |
|
