Оригинальный
номер |
Название |
Заказ |
| (2) |
054103101F |
cylinder block with pistons also use: |
|
| (2) |
034103101R |
cylinder block with pistons also use: |
|
| (2) |
034103101S |
cylinder block with pistons also use: |
|
| (2) |
035103101P |
cylinder block with pistons |
|
| (2) |
035103101Q |
cylinder block with pistons |
|
| (20) |
N 0245077 |
pipe clip AL32-50 |
|
| (21) |
054103227A |
breather tube also use: |
|
| - |
N 0122265 |
spring washer B6X12X0,5 |
|
| - |
054103223A |
hose |
|
| - |
054103223 |
hose |
|
| - |
049103389 |
cap 8MM |
|
| - |
N 10258201 |
pipe clip AL12-22 |
|
| - |
N 0245077 |
pipe clip AL32-50 |
|
| - |
N 90561801 |
pipe clip AL16-28 |
|
| 1 |
. |
discontinued / replacement: 068 103 171 F |
|
| 11 |
N 0138492 |
seal A14X20 |
|
| 12 |
N 90288901 |
sealing plug M14X1,5X16 |
|
| 13 |
035103601D |
oil sump |
|
| 13A |
034115221 |
baffle |
|
| 14 |
N 90008401 |
hexagon head bolt c/w shoulder M6X14 |
|
| 15 |
054103609 |
gasket for oil sump |
|
| 16 |
034121137 |
union |
|
| 17 |
035103635 |
tube for oil dipstick |
|
| 18 |
059115721 |
threaded union |
|
| 19 |
054103129A |
breather assy. |
|
| 20 |
N 90561801 |
pipe clip AL16-28 |
|
| 21 |
035103221F |
breather hose shorten to: A17,5X3,5X440 |
|
| 22 |
026103139 |
parallel dowel pin 6M6X20 |
|
| 23 |
077103175B |
valve |
|
| 24 |
034103179 |
adapter |
|
| 25 |
034133431A |
retaining plate |
|
| 26 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 27 |
N 01023911 |
hexagonal head bolt M8X18 |
|
| 28 |
035103157B |
oil spray jet |
|
| 29 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 3 |
N 90130001 |
hexagonal head bolt AM10X80 |
|
| 30 |
N 0147506 |
allen key head bolt M6X10 |
|
| 4 |
N 0432072 |
parallel dowel pin 8H8X14 |
|
| 5 |
059103113 |
locking cover 36,6 |
|
| 6 |
N 0119033 |
locking cover 16 |
|
| 7 |
068103171F |
sealing flange rear |
|
| 8 |
026103181B |
gasket |
|
| 9 |
N 01021612 |
hexagonal head bolt also use: M6X18 |
|
