Оригинальный
номер |
Название |
Заказ |
| (1) |
8L3809602A |
side panel right outer |
|
| (1) |
8L4809602 |
side panel right outer |
|
| (1) |
8L7809605 |
side panel left outer |
|
| (1) |
8L4809605 |
side panel left outer |
|
| (1) |
8L7809602 |
side panel right outer |
|
| (10) |
8L0810268B |
reinforcement for side panel right inner |
|
| (11) |
8L0809458A |
gusset plate for side panel right rear |
|
| (11B) |
8L0809803Q |
mounting for tie-down eye left/right |
|
| (11B) |
8L0809804A |
mounting for tie-down eye right |
|
| (12) |
8L0810416E |
gusset plate for c-pillar right rear |
|
| (13) |
8L0809650C |
mounting for tail light right |
|
| (14) |
8L0810171B |
wheel housing-plastic material left rear |
|
| (14) |
8L9810171A |
wheel housing-plastic material left rear |
|
| (15) |
8L9810172A |
wheel housing-plastic material right rear |
|
| (15) |
8L0810172B |
wheel housing-plastic material right rear |
|
| (2) |
8L9810209 |
hinge reinforcement left |
|
| (2) |
8L0810210A |
hinge reinforcement right |
|
| (2) |
8L9810210 |
hinge reinforcement right |
|
| (3) |
8L4809630 |
rip plate for side member right |
|
| (3) |
8L4809629 |
rip plate for side member left |
|
| (4) |
8L4809224B |
b-pillar, inner right |
|
| (4) |
8L7809224B |
b-pillar, inner right |
|
| (4) |
8L3809224C |
b-pillar, inner right |
|
| (4) |
8L4809223B |
b-pillar, inner left |
|
| (4) |
8L7809223B |
b-pillar, inner left |
|
| (7) |
8L4809755 |
filler plate for b-pillar left |
|
| (7) |
8L3810226 |
filler plate for b-pillar right |
|
| (7) |
8L4809756 |
filler plate for b-pillar right |
|
| (8) |
8L7809404B |
side panel, inner right rear |
|
| (8) |
8L4809404B |
side panel, inner right rear |
|
| (8) |
8L7809403B |
side panel, inner left rear |
|
| (8) |
8L4809403B |
side panel, inner left rear |
|
| (8) |
8L3809404G |
side panel, inner right rear |
|
| (9) |
8L4809412 |
wheel housingliner right outer |
|
| (9) |
8L4809411 |
wheel housingliner left outer |
|
| (9) |
8L9809411 |
wheel housingliner left outer |
|
| (9) |
8L3809412A |
wheel housingliner right outer |
|
| (9) |
8L9809412 |
wheel housingliner right outer |
|
| - |
N 90830601 |
rivetted cap nut M6 |
|
| - |
000800981A |
sheet metal plate 300X1500X0,8 |
|
| - |
000800981C |
sheet metal plate 800X1500X0,8 |
|
| - |
000800981 |
sheet metal plate 200X1500X0,8 |
|
| - |
000800981B |
sheet metal plate 500X1500X0,8 |
|
| 1 |
8L3809605B |
side panel left outer |
|
| 10 |
8L0810267C |
reinforcement for side panel left inner |
|
| 11 |
8L0809457A |
gusset plate for side panel left rear |
|
| 11B |
8L0809803A |
mounting for tie-down eye left |
|
| 12 |
8L0810415E |
gusset plate for c-pillar left rear |
|
| 13 |
8L0809649C |
mounting for tail light left |
|
| 14 |
8L0810171 |
wheel housing-plastic material left rear |
|
| 15 |
8L0810172 |
wheel housing-plastic material right rear |
|
| 16 |
N 90821401 |
expanding nut D4,8 |
|
| 17 |
N 10433701 |
snap nut 4,8X18,6X16 |
|
| 18 |
N 90775001 |
torx socket head panel screw 4,8X16 |
|
| 19 |
8L0805271 |
water drain valve 19,8 |
|
| 2 |
8L0810209A |
hinge reinforcement left |
|
| 3 |
8L0809629 |
rip plate for side member left/right |
|
| 4 |
8L3809223C |
b-pillar, inner left |
|
| 5 |
8D0809237 |
threaded plate |
|
| 7 |
8L3810225 |
filler plate for b-pillar left |
|
| 8 |
8L3809403G |
side panel, inner use if required: left rear |
|
| 9 |
8L3809411A |
wheel housingliner left outer |
|
