Оригинальный
номер |
Название |
Заказ |
| (19) |
443862192 |
4 way connector F 81-E-000 001>> |
|
| (21) |
056131851 |
thermo-pneumatic valve |
|
| (22) |
049131503E |
exhaust recirculation valve F 81-E-000 001>> |
|
| (22) |
034131503A |
exhaust recirculation valve F >> 81-E-000 001 |
|
| (22) |
049131503F |
exhaust recirculation valve F >> 81-D-250 000 |
|
| (22) |
034131503A |
exhaust recirculation valve |
|
| (29) |
N 0208091 |
threaded union L12M-B |
|
| (29) |
035129637E |
threaded union |
|
| (38) |
035133595R |
hose F 81-E-000 001>> |
|
| (3B) |
035133783L |
hose F 81-E-000 001>> |
|
| (42) |
034133394F |
hose F 81-E-000 001>> |
|
| (6) |
N 90080102 |
hose in coils of 5m order unit 5 shorten if necessary F 81-E-000 001>> |
|
| (6) |
049133394E |
hose F 81-E-000 001>> |
|
| - |
049133382D |
joint pipe F 81-E-000 001>> |
|
| - |
034133394F |
hose F 81-E-000 001>> |
|
| - |
035133335 |
cap F 81-E-000 001>> 8 |
|
| - |
N 90080102 |
hose in coils of 5m order unit 5 7,5X3 |
|
| - |
N 90561801 |
pipe clip LC16-27 |
|
| - |
N 0122323 |
spring washer B12X24X1,2 |
|
| - |
N 0111629 |
hexagonal nut M12X1,5 |
|
| - |
035133965 |
vacuum switch |
|
| - |
035133563F |
vacuum limiter |
|
| - |
035133367B |
hose F 81-E-000 001>> |
|
| - |
035133783L |
hose F 81-E-000 001>> |
|
| - |
035133382D |
connection piece F 81-E-000 001>> |
|
| - |
N 0202811 |
hose in coils of 5m order unit 5 7X3 |
|
| - |
N 0201391 |
tube in coils of 5m order unit 5 4X1 |
|
| - |
N 0203535 |
hose in coils of 5m order unit 5 3,5X2 |
|
| - |
034133847 |
plug F 81-E-000 001>> 5MM |
|
| - |
035133382AF |
connection piece F 81-E-000 001>> |
|
| 1 |
035133595K |
hose |
|
| 17 |
067133847 |
plug 7,5 |
|
| 18 |
035906283 |
solenoid change-over valve |
|
| 19 |
056129971 |
y-piece 4/4/4 |
|
| 2 |
N 0241261 |
pipe clip 9X21 |
|
| 20 |
035133517 |
non-return valve |
|
| 21 |
058131851A |
thermo-pneumatic valve |
|
| 21A |
N 0138115 |
seal A10X13,5 |
|
| 23 |
026131547 |
gasket |
|
| 24 |
N 0102228 |
hexagonal head bolt M6X22 |
|
| 25 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 26 |
035131637F |
connecting pipe |
|
| 27 |
N 0208231 |
die ring L12 |
|
| 28 |
N 0210251 |
union nut AL12 |
|
| 29 |
N 0208091 |
threaded union L12M-B |
|
| 3 |
035133382C |
connection piece 8MM |
|
| 32 |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| 33 |
N 0122253 |
spring washer B5X11X0,5 |
|
| 34 |
N 01100624 |
hexagonal nut M6 |
|
| 35 |
049131185D |
junction |
|
| 36 |
N 0116644 |
washer B4,3X12X1 |
|
| 37 |
N 0139553 |
oval head panel screw ST3,9X19-C |
|
| 39 |
N 0206471 |
pipe clip D1-24X15 |
|
| 4 |
035129737B |
double t piece |
|
| 40 |
171919825 |
vacuum switch |
|
| 5 |
035133777 |
plug 3/12,5MM |
|
